Hospital Semi Fowler Bed with ABS Panel

Price 6500.0 INR/ Unit

Get a Price/Quote

MOQ : 5 Units

Hospital Semi Fowler Bed with ABS Panel Specification

Height
Approx. 600 mm from floor

Specific Usage
Hospital, Clinic and Nursing Home patient care

Dimension (L*W*H)
2050 mm x 900 mm x 600 mm (approx.)

General Use
Medical Furniture

Design
Pre-treated & epoxy powder coated, Perforated steel tops

Regional Style
Indian Standard

Furniture Type
Hospital Semi Fowler Bed

Material
Mild steel frame with ABS head and foot panel

Metals Type
Mild Steel

Folded
No

Function
Manual backrest adjustment through crank mechanism

Back Rest Lifting Angle
0 - 75 (10)

Size
Standard Single Bed Size

Weight
45 kg (approx.)

Maximum Loading
150 kg (approx.)

Feature
Durable, Corrosion Resistance, Adjustable Backrest, ABS Moulded Panels and corner buffers

Crank Handle
Foldable, ergonomically designed for smooth operation

Head and Foot Panel Removal
Easily detachable for quick access during emergency

Finish
Epoxy powder coated, scratch and corrosion resistant

Color
White with blue/cream panels

Safety Features
Provision for IV pole, optional side rails

Mattress Platform
Perforated CRC sheet top for ventilation and patient comfort

Legs
Four legs with protective ABS outer cover and non-rusting finish

Head/Foot Board Material
ABS (Acrylonitrile Butadiene Styrene) plastic, removable for cleaning

Compliance
ISO and CE as per manufacturer

Assembly
Knock-down construction for easy transportation and installation

Mobility
Optional castors available for easy movement

About Hospital Semi Fowler Bed with ABS Panel

ICU Bed (Intensive Care Unit Bed) Description:

ICU bed ek special hospital bed hota hai jo critically ill patients ke liye use kiya jata hai. Ye normal bed se advanced hota hai aur patient ki condition monitor aur manage karne ke liye design kiya jata hai.

Main features:

Adjustable positions Head, legs, aur height ko adjust kiya ja sakta hai.

Side rails Patient ko girne se bachane ke liye.

Monitoring support Ventilator, oxygen, heart monitor, IV stand attach karne ki facility.

Emergency controls CPR aur quick positioning ke liye.

Comfort & pressure relief Bed sores se bachane ke liye special mattress.

Use kahan hota hai?

Serious accident cases

Heart attack patients

Surgery ke baad critical care

Breathing problems

Severe infections

Durable Construction for Patient Safety

Engineered from mild steel with an ABS head and foot panel, the bed resists corrosion and scratches due to its epoxy powder coating. The robust frame supports patients up to approximately 150 kg, while the ABS protective leg covers enhance hygiene and protect against rust, ensuring long-term durability in high-traffic medical settings.

Adjustable Comfort and Easy Maintenance

Featuring a manual crank mechanism for smooth backrest adjustment (0-75), the bed supports multiple patient positions. The detachable ABS head and foot panels allow rapid access during emergencies and make cleaning simple. The ventilated, perforated CRC mattress platform further promotes patient comfort and hygiene during extended stays.

Mobility and Compliance Features

This bed offers optional castors for easy movement within hospital wards or rooms. Safety options like side rails and an IV pole provide added security and convenience. Designed to meet ISO and CE requirements, the bed's knock-down construction ensures effortless transportation and assembly, making it suitable for a wide range of medical environments.

FAQ's of Hospital Semi Fowler Bed with ABS Panel:

Q: How can the backrest angle of the Semi Fowler Bed be adjusted?

A: The backrest of this hospital bed can be manually adjusted from 0 to 75 degrees using an ergonomically designed crank handle. This allows caregivers to easily set the desired angle for patient comfort and medical requirements.

Q: What materials are used for the head and foot panels, and how are they maintained?

A: The head and foot panels are made from high-quality ABS (Acrylonitrile Butadiene Styrene) plastic, which is both durable and easy to clean. They are also removable, enabling quick cleaning and unobstructed access during medical emergencies.

Q: When is it beneficial to remove the head and foot panels?

A: The removable ABS panels are particularly useful during emergencies as they allow rapid access to the patient. They also simplify cleaning and maintenance, promoting hygiene in patient care settings.

Q: Where can this hospital bed be used?

A: This Semi Fowler Bed is ideal for patient care in hospitals, clinics, and nursing homes, designed according to Indian Standard regional requirements and suitable for various medical environments.

Q: What process is involved in assembling the bed on-site?

A: The bed features a knock-down construction, which means it can be easily transported in parts and quickly assembled at its final location with standard tools. This process simplifies logistics and installation in healthcare facilities.

Q: How do the optional castors and side rails enhance the bed's usability?

A: Optional castors provide effortless movement and repositioning of the bed within a facility, while side rails (available separately) ensure patient safety by preventing accidental falls.

Q: What are the key benefits of the perforated mattress platform?

A: The perforated CRC sheet top enhances airflow under the patient, reducing heat and moisture buildup. This ventilation improves patient comfort, especially during long-term stays, and aids in maintaining a hygienic environment.
